手动粉末压片机

发布时间:2021-10-19 17:21人气:
  • 5654
手动粉末压片机
型号:YXY-YP24T
产品介绍:手动粉末压片机广泛用于新材料,超导,粉末陶瓷,新型电源,建材等领域,可以和钙铁分析,红外光谱(IR),X荧光(XRF)分析仪器配套使用,配上不同形状的模具,可以压出不同形状不同尺寸的片子。用特定的模具可以压制成各种各样的片,柱及异型体,组合体等进行科学研究。
     功能特点:
1、 体积小,重量轻,不漏油,可以放到手套箱内使用
2、 一体式主板结构,没有密封连接,减少漏油现象
3、 稳定性强,不掉压
4、 可以与其他分析仪器配套使用
规格参数:
型号 YXY-YP24T
压力范围 0-24T
一体式结构 主板、油池、油缸无密封结构
立柱数量 4根
活塞直径 Φ95mm镀铬油缸
活塞行程 30mm
压力稳定性 ≤1MPa/10min
工作台直径 110mm
加压方式 手动
压力表 压力、压强双刻度压力表
工作空间 85(L)×85(W)×170(H)mm
产品尺寸 330(L)×263(W)×410(H)mm
重量 42KG
Manual powder tablet press
Model: YXY-YP24T
Product introduction: The manual powder tablet press is widely used in new materials, superconductors, powder ceramics, new power sources, building materials and other fields. It can be used with calcium-iron analysis, infrared spectroscopy (IR), X fluorescence (XRF) analysis instruments, and With different shapes of molds, you can press different shapes and sizes of tablets. It can be pressed into a variety of tablets, columns, special-shaped bodies, composite bodies, etc. with a specific mold for scientific research.
      Features:
1. Small size, light weight, no oil leakage, and can be used in a glove box
2. One-piece main board structure, no sealed connection, reducing oil leakage
3. Strong stability, no pressure drop
4. It can be used with other analytical instruments
Specifications:

model YXY-YP24T
Pressure range 0-24T
One-piece structure No sealing structure for main board, oil sump, and oil cylinder
Number of columns 4 pieces
Piston diameter Φ95mm chrome-plated cylinder
Piston stroke 30mm
Pressure stability ≤1MPa/10min
Table diameter 110mm
Pressure method Manual
Pressure gauge Pressure and pressure double scale pressure gauge
Workspace 85(L)×85(W)×170(H)mm
Product Size 330(L)×263(W)×410(H)mm
weight 42KG
